Metabo TF 100 M

MachineInfoBox

Metabo TF 100 M

Synonyms: DE: Frästisch, Oberfrästisch,
stationäre Oberfräse
Material: wood
Access Requirements: The query description has an empty condition.Property "Needs Introduction" (as page type) with input value "The query description has an empty condition." contains invalid characters or is incomplete and therefore can cause unexpected results during a query or annotation process.
Manual: http://www.targetmanufacturing.co.uk/wp-content/uploads/Elektra-Beckum-TF100-Spindle-Moulder.pdf
Tutors: The query description has an empty condition.
Similar (More or Less): Https://wiki.comakingspace.de/Sauter OFL2.0 Router Table

... further resultsProperty "Has caption" (as page type) with input value "Vertical Bandsaws, Vertical Bandsaws, CNC Router, Mechanical Hand Tool, 3D Printers, 3D Printers, 3D Printers, 3D Printers, 3D Printers, 3D Printers, Oscilloscope, Oscillating Tool, Multimeters, Chop Saw, Belt and Disc Sander, Bench Grinders, Bench Grinders, Table Saw, Handheld Circular Saws, Shop Vacs, Shop Vacs, Biscuit Joiner, Chop Saw, Handheld Circular Saws, CNC Router, Compressor, Archived:Corded Drills, Archived:Corded Drills, Cordless Drills, Cordless Disc Grinder, Cordless Drills, Jigsaws, Vice, Lab Power Supplies, Lab Power Supplies, Corded Disc Grinder, Corded Disc Grinder, Wood Lathes, CNC Mill, Wood Lathes, Laser Cutter, Eccentric Sanders, Kitchen Equipment, Chop Saw, Wood Lathe Accessory, Laser Printers, Audio Equipment, Audio Equipment, Wood Lathe Accessory, Wood Lathe Accessory[[:Special:Ask/-5B-5BHas-20Internal-20AssetID::+-5D-5D/-3FHas-20Internal-20Category/mainlabel=-2D/limit=50/offset=50/format=plainlist/link=none/headers=hide/default=Metabo-20TF-20100-20M" contains invalid characters or is incomplete and therefore can cause unexpected results during a query or annotation process.<ul><li>"]]" is not a number.</li> <!--br--><li>Some use of "" in your query was not closed by a matching "".</li></ul>|]]


Overview

The Metabo TF 100 M is a compact spindle moulder (router table) designed for precision woodworking. It is intended for routing, profiling, grooving, chamfering, and edge finishing of solid wood and wood-based materials. The machine provides a stable work surface and can be equipped with a sliding table to improve the handling of larger workpieces.

Intended Use

The machine is intended for machining wood and wood-based materials.

Typical operations include:

  • Edge profiling
  • Grooving
  • Rebating
  • Chamfering
  • Decorative routing
  • Small-series woodworking

Suitable materials include:

  • Solid wood
  • MDF
  • Plywood
  • Particle board
  • Other wood-based panels

Features

Safety

Always observe the following safety precautions:

  • Wear safety glasses.
  • Wear hearing protection.
  • Use an appropriate dust extraction system.
  • Ensure all guards are installed before operation.
  • Only use approved cutters in good condition.
  • Disconnect the machine from the power supply before changing tooling.
  • Never exceed the permitted cutter diameter or spindle speed.
  • Use push sticks or push blocks whenever appropriate.

Tool Diameter and Operating Speed

The appropriate spindle speed depends on the diameter and type of the cutting tool used. A reference table with the recommended operating speeds for different tool diameters is located on the rear side of the machine. Always select a spindle speed that matches the installed cutter and never exceed the maximum permissible speed specified by the tool manufacturer.

Limitations

  • Intended exclusively for woodworking.
  • Not suitable for machining metal or plastics unless specifically approved by the tooling manufacturer.
  • Large workpieces should be supported using roller stands.
  • Only use cutters that comply with the specified dimensions and speed ratings.
  • The machine should always be operated with effective dust extraction.

Known Issues & Possible Workarounds

Dust extraction is insufficient

Ensure the extraction hose is properly connected and that the extraction system provides adequate airflow.

Tear-out on end grain

Use a backing board and sharp cutters to minimize tear-out.

Difficult handling of long workpieces

Use the sliding table together with roller supports.

Rough cutting results

Inspect the cutter for wear and replace or sharpen it if necessary.

Accessories

Common accessories include:

  • Sliding table
  • Mitre fence
  • Featherboards
  • Push sticks
  • Push blocks
  • Dust extraction adapter
  • Roller stands
  • Additional fence inserts

This tool is not ready for use yet since not all commissioning steps have been completed. The process is not yet tracked on GitHub. Feel free to contribute to making it usable, any help is very welcome!

Task comment Status
Name the tool: - pending
Take a picture - pending
Find the manual as PDF needed for all machines - add a link to the InfoBox or comment where you could not find it pending
Documentation this page, status: in commissioning pending
Print QR-Code use the MachineQR Factory pending
Introduction - pending
Security Check to be done or witnessed by a manager pending
Test to be done or witnessed by a manager pending
tool's name, owner and approx. value provide to Johannes for inventorization pending
Last step: make it available physically and in the wiki - then delete this template pending
