Summary
Two common failures when laser cutting jigsaw-puzzles: If you don't put anything underneath the workpiece, puzzle pieces may just slip through the knife bed into the collection tray. The result are pieces which are being incorrectly (purple ellipses) cut since they are tilted, or only cut partially (purple rectangle).
